Round Seamless 316 Welded Stainless Steel Tube For Industry Machinery

Ask Lasest Price
Brand Name :	NADONG
Model Number :	316
Certification :	ISO SGS
Price :	$1200-$1800
Payment Terms :	L/C, T/T
Supply Ability :	1000 ton per month
Delivery Time :	15 working days
MOQ :	1 Ton

Add to Cart

Product Details
Company Profile

Round Seamless 316 Welded Stainless Steel Tube For Industry Machinery

Custom Size Seamless 316 Stainless Steel Tube For Industry Machinery

We supplie both seamless and welded 316/316L stainless steel Tube. When your application requires a high amount of corrosion resistance, 316/316L Stainless Steel is the right material for your company. The main difference between this grade of stainless steel and 304/304L stainless steel is that 316/316L stainless steel had molybdenum. The addition of this element makes 316 stainless steel able to remain durable in harsh, corrosive environments.

Specfications

Product Name	Stainless Steel Pipe/Tube
Technology	Hot Rolled Industrial Stainless Steel Tube Cold Rolled Decorative Stainless Steel Pipe
Material	201, 202, 301, 302, 304, 304L, 310S, 316, 316L, 321, 430, 430A, 309S, 2205, 2507, 2520, 430 , 410, 440, 904Lect, Or Customized
Thickness	0.4-50 mm
Length	1-12 m
Outer Diameter(OD)	10-2000mm
Standard	ASTM, JIS, GB, AISI, DIN, BS,EN
Certifications	ISO 9001 BV SGS
Packing	Industry standard packaging or according to client's requirement
Brand	TISCO,ZPSS,Baosteel,POSCO,LISCO,YUSCO,Ansteel, QPSS,JISCO,HXSCO, Chengde,Yongjin,Tsingshan,Shouyang,HW
Payment terms	30%T/T in advance, the balance against the B/L copy
Delivery time	Fast delievery in 7 days,up to order quantity
Warehose Stcok	5000 tons per month

Chemical Composition

Specification	Grade	Chemical Composition(wt%)
Specification	Grade	C	Mn	Ni	Cr	Mo	Ti
ASTMJIS	316L/022Cr17Ni12Mo2	≤0.03	≤2.0	10.0-14.0	16.0-18.0	2.0-3.0	-
JIS	SUS316L	≤0.03	≤2.0	12.0-15.0	16.0-18.0	2.0-3.0	-
ASTMJIS	316Ti/SUS 316Ti	≤0.08	≤2.0	10.0-14.0	16.0-18.0	2.0-3.0	5*(C+N)-0.7

Properties

Spec	Grade	Mechanical Property				Physical Property
Spec	Grade	Y.S (N/MM2)	T.S (N/MM2)	EL (%)	HRB	Specific Heat (J/g℃)	Modulus of Elasticity (KN/mm2)
ASTM/GB	316L/022Cr17Ni12Mo2	≥170	≥485	≥40	≤95	0.5	193
JIS	SUS316L	≥175	≥480	≥40	≤90	0.5	193
ASTM	316Ti	≥205	≥515	≥40	≤95	0.5	200

316L: Widely used in corrosion-susceptible environment and some mechanical components those are difficult to make heat treatment after forming in more corrosive environment.

316Ti: Mainly used for industrial components.
